ALTEA MAXI ROUND 230VAC | LLD Light

ALTEA MAXI ROUND 230Vac

Ground recessed

ALTEA MAXI ROUND 230Vac

6W

IP67IK08

53 mm

drive 2000kg

Compose the code

Supply	Led Color	Optics	Optics 2	Cable	Finishing	Body Finishing	Plate Finishing	Trim Finishing	Spacer	Pole Adapter	Arms Lenght	Base	Dimmer	Cri	Filter
230Vac	2700 K3000 K4000 K	20° 35° 43° diffused 66°		WP 50cmWP 5mWP 10mWP 15m	Anodized aluminiumSteelBrushed steel									>80	HC,BC,BD HC, BC - 20°,35°,43°,66 only \| BD - Diffused only

Technical features
Installation
Supply
Accessories
Download

Finishing.01 – Kg 0,23 / Finishing.06.10 – Kg 0,31

Material:

Anticorodal aluminum body
Aluminum or AISI 316L stainless steel bezel
Tempered glass

Connection:

230Vac – Mains voltage

Installation:

Recessed in the ground with a housing (not included)
Recessed in plasterboard or wood with a spring (not included)
Recessed in masonry with a housing (not included)

Phase cut dimmer

Accessories needed for installation:

ML053 - Torsion spring
CAW53 - Housing box
CAI53 - Housing box
HC - The honeycomb filter is an anti-glare filter and must be ordered contextually to the lighting fixture
BC - The Black & Clear filter, an anti-glare screen half black screen-printed and half transparent, must be ordered contextually to the lighting fixture
BD - The Black & Diffused filter, an anti-glare and semi-diffusing screen half black and half screen-printed diffusing, must be ordered contextually to the lighting fixture

NOTE: Choose between CAW53 and CAI53

Documents available for download:

INSTRUCTIONS DATA SHEET LDT PHOTOMETRY IES PHOTOMETRY
