ALTEA RECESSED ROUND

Ground recessed

ALTEA RECESSED ROUND

1W (350mA) - 1,6W (500mA) - 2,5W (700mA) // 2,2W (24Vdc)

IP67IK08

32 mm

drive 2000kg

Compose the code

Supply	Led Color	Optics	Optics 2	Cable	Finishing	Body Finishing	Plate Finishing	Trim Finishing	Spacer	Pole Adapter	Arms Lenght	Base	Dimmer	Cri	Filter
C.C. 24Vdc	2200 K2700 K3000 K4000 KRedGreenBlu	15° 28° 64° 16x48°		WP 50cmWP 5mWP 10mWP 15m	Anodized aluminiumSteelBrushed steel									>80	HC,BC BC - 15°,28°,64° only

Technical features
Installation
Supply
Accessories
Download

C.C. Finishing.01 .07 – Kg 0,10 / C.C. Finishing.06.10 – Kg 0,13 / 24Vdc Finishing.01 .07 – Kg 0,12 / 24Vdc Finishing.06.10 – Kg 0,15

Material:

Anticorodal aluminum body
Aluminum or AISI 316L stainless steel bezel
Tempered glass

Connection:

C.C. - Series
24Vdc - Parallel

Installation:

Recessed in the ground with a housing (not included)
Recessed in plasterboard or wood with a spring (not included)
Recessed in masonry with a housing (not included)

Controller

Phase cut dimmer

NOTE: For power options, visit the Power Supplies section of the site.

Accessories needed for installation:

ML032 - Torsion spring
CAW32 - Housing box
CAI32 - Housing box
HC - The honeycomb filter is an anti-glare filter and must be ordered contextually to the lighting fixture
BC - The Black & Clear filter, an anti-glare screen half black screen-printed and half transparent, must be ordered contextually to the lighting fixture

NOTE: Choose between CAW32 and CAI32

Documents available for download:

INSTRUCTIONS DATA SHEET LDT PHOTOMETRY IES PHOTOMETRY
